Overview

What is a Decoder?

A Decoder restructures and augments inbound data to optimise the structure and contents for query and analysis.

It is installed between standard Google-managed inbound BigQuery data transfers and subsequent transformation, analysis or automation activities.

flowchart LR
 source_data(["Source Data"]) --> inbound_data["Inbound<br>Data Transfer"] --> decoder{{"Decoder"}} --> outbound_data["Outbound<br>Data Assets"] --> downstream_activities_gc(["Downstream<br>Data Activities"])

 style decoder fill:#ffffff,stroke:#333,stroke-width:2px

It efficiently and reponsively curates downstream data assets and is configurable upon deployment, with pre-configured installation functions for connection to specific business intelligence tools, cross-cloud storage buckets or even Google BigTable.

It is responsive to newly arriving data in a cost-optimal manner and requires minimal ongoing maintenance or monitoring.

Why would you need one?

Inbound data structures are typically designed for optimal storage and schema stability, not for simplicity of modelling, query or analytics. Specifically, nested data structures pose challenges as the structure of the nested data needs to be known ahead of time in order to extract meaningful data. This also applies to JSON data.

Historically this has meant that transforming this data required painfully hand-crafting queries with a verbose, unintuitive and uncommon query syntax, slowing down subsequent data-related activities.

Many Google-managed inbound data transfers also do not arrive at a consistent time every day, which can be challenging to control for efficiently and reliably.

How does it work?

Decoders are installed by executing a BigQuery function with installation-specific configuration arguments. Installation involves the following automated stages:

  1. Profile data structure, contents and types
  2. Build decoder functions based on configuration and data profile
  3. Build output assets (typically date-partitioned tables)
  4. Deploy automation function
flowchart LR
 profile_data["Profile<br>Data"] --> build_decoder_functions["Build<br>Decoder<br>Functions"] --> build_output_assets["Build<br>Output<br>Assets"] --> deploy_automation_function["Deploy<br>Automation<br>Function"]

Once a decoder is installed, the output data assets can then be:

  • queried directly;
  • connected directly to business intelligence tools;
  • used as an input to simplified transformation models; and
  • extended with SQL to customise subsequent data transformation.

Decoders are built using a hierarchy of functions and use native (but extended) BigQuery functionality, so do not require external plaforms or API calls. Decoders can be deployed on whitelisted datasets, by users with the appropriate permissions on the specific installation function.

A simple RUN_FLOW automation function is deployed in the decoder dataset, which calls an external function to check and compare inbound shard and outbound partition metadata. New date partitions are identified, transformation/augmentation logic is applied to the newly-arrived data and the output data tables are updated incrementally.

This is triggered on a regular schedule using a simple BigQuery scheduled query, and can also be called manually to refesh specific partition subsets of the outbound tables.

Access to automation functions is granted to permitted users on whitelisted datasets.

Where is it installed?

A decoder is installed in a configurable dataset (within the same region as the inbound data), but typically the same dataset as the inbound data.
